8-Packs SPST Bistable Relay Module 12VDC with Latching Control for Industrial Automation Circuits
Product details
| Management number | 239314431 | Release Date | 2026/07/14 | List Price | US$10.00 | Model Number | 239314431 | ||
|---|---|---|---|---|---|---|---|---|---|
| Category | |||||||||
Technical Specifications Relay Configuration SPST Bistable Relays (EN 61810-1 Certified) Contact Rating: 10A @ 250VAC (UL 508) / 10A @ 30VDC (IEC 60664-1) Mechanical Lifetime: 1×10⁶ Operations Control Logic Dual-Input Trigger System: Momentary Pushbutton Interface TTL-Level Signal (0-5V Active Low) Latching Time: <20ms (EN 60947-5-1) Power Requirements 12VDC ±10% (Min. 100mA) Reverse Polarity Protection: 1A Fast-Acting Fuse Thermal Management Operating Temp: -40℃ to +85℃ (EN 60721-3-4) Max Load Duty Cycle: 60% @ 15A pplication Scenarios Industrial Automation Control Circuits HVAC System Actuators (EN 14597) Safety Interlock Systems (ISO 13849 PLc) Energy Management Switching Nodes
- IEC 60947-1 Compliant Terminal Block:Torque-controlled screw clamp (0.5-1.2Nm) with VDE 0611-1 certified cage clamp design
- AgSnO2 Contact Material:Silver-tin oxide alloy contacts (EN 60128-1) with <50mΩ contact resistance @10A
- SPDT Contact Configuration:Single-pole dual-throw (EN 60664-3) with 0.5mm contact gap
- 10A/250VAC Switching Capacity:UL 508 & IEC 60947-5-1 certified (AC-15 250V / DC-13 30V)
- IP20 Protected DIN Rail Mount:EN 60715-compliant 35mm rail mounting with integrated arc chamber
| UPC | 766717976785 |
|---|---|
| ASIN | B0GRVN5V4N |
| Model | H3-HBB0152 |
| Brand Name | KEAcvise |
| Unit Count | 1.0 Count |
| Item Weight | 22.68 g |
| Part Number | H3-HBB0152 |
| Coil Voltage | 12 Volts (DC) |
| Manufacturer | KEAcvise |
| Mounting Type | DIN Rail Mount |
| Connector Type | Screw |
| Current Rating | 2 Amps |
| Operation Mode | Automatic |
| Contact Material | Silver Tin Oxide |
| Specification Met | IEC/EN 60947 |
| Included Components | Blu-ray |
| Warranty Description | KEAcvise |
| Contact Current Rating | 10 Amps |
| Minimum Switching Voltage | 12 Volts (DC) |
